Semiautomatic box sealing machine CJ-3500-H
Equipment model: CJ-3500-H
Outline specification: 3500 (L) * 620 (W) * 2000 (H) mm
Equipment power: AC220V/3.2KW/50HZ
Motor power: 0.75KW
Air source pressure: total pressure 2-6kg/cm ² Rubber pump air pressure 1-3kg/cm ²
Type of adhesive used: hot melt adhesive
Glue application method: automatic glue spraying
Rubber cylinder capacity: 5kg/h
Paper box specifications: customizable according to demand
Paper box specifications: customized according to customer specifications
Work efficiency: 65-80 boxes/min
Operating temperature: 160-220
Working pressure: 0.45-0.7MPa
Applicable paper box material: 200-350g/㎡
Number of spray points: 1-24 adjustable
Glue spraying system: Meichan and Hehe Asset System
Body weight: 650kg
- Parameters
Equipment model: CJ-3500-H
Outline specification: 3500 (L) * 620 (W) * 2000 (H) mm
Equipment power: AC220V/3.2KW/50HZ
Motor power: 0.75KW
Air source pressure: total pressure 2-6kg/cm ² Rubber pump air pressure 1-3kg/cm ²
Type of adhesive used: hot melt adhesive
Glue application method: automatic glue spraying
Rubber cylinder capacity: 5kg/h
Paper box specifications: customizable according to demand
Paper box specifications: customized according to customer specifications
Work efficiency: 65-80 boxes/min
Operating temperature: 160-220
Working pressure: 0.45-0.7MPa
Applicable paper box material: 200-350g/㎡
Number of spray points: 1-24 adjustable
Glue spraying system: Meichan and Hehe Asset System
Body weight: 650kg
Demo Video
Equipment
CJF-3500-H semi-automatic box sealing machine is a new model that our company has further upgraded the box sealing machine series products. It is a new product that integrates machinery, electricity, gas, and light. The complete set of equipment is made of SUS304 stainless steel material, which meets the standards of the food and medical industry; Adopting a dual circuit design combined with imported safety relays, magnetic coded contact inductors, PC protective covers, and interlocking induction switches, ensuring absolute safety for operators during operation; The equipment is equipped with servo transmission to prevent product damage caused by jamming. The imported glue spraying system and high-precision sensors can achieve the switching of point spraying, section spraying, and line spraying for paper boxes. The equipment can be used independently or can be equipped with inkjet printers, packaging production lines, labeling machines, etc. for synchronous use.
Features&Advantages
This product is designed and manufactured based on the customer's actual production needs, and has the following advantages:
1. Environmentally friendly and efficient
2. The cardboard box specifications have high universality, and the transfer is efficient, convenient, and fast
3. Hot melt adhesive can meet the requirements of point spraying and line spraying
4. Human machine interface operation, capable of pre storing 45 sets of box gauge parameters
5. Exquisite appearance of equipment
6. The equipment adopts a dual circuit safety circuit combined with a safety door sensor, fundamentally eliminating safety issues during operation
7. The front section of the equipment can be equipped with an automatic boxing production line, while the rear section can be equipped with automatic labeling, coding, boxing, and plastic sealing equipment
